The Megawin MG82F6D17AE20 is a high-performance 8-bit microcontroller featuring an 8051-based architecture. Designed for embedded system applications, it offers reliable processing capabilities for industrial control, consumer electronics, and automation projects requiring precise digital logic integration.
The MG82F6D17AE20 is a high-performance 1T 8051-based 8-bit microcontroller from Megawin Technology, designed for industrial control, motor control, LED lighting, home appliances, and embedded applications.
Key Specifications
Parameter Specification
Core 1T 80C51 (8051)
Flash Memory 16 KB
SRAM 1 KB
Operating Voltage 1.8V – 5.5V
Maximum CPU Frequency Up to 36 MHz
ADC 12-bit, 8-channel
UART 2
SPI 1
I²C/TWI Hardware + Software
PWM Up to 8 Channels
Timers 4 × 16-bit + RTC
GPIO Up to 17 I/O
Package DIP-20 (AE20)
Operating Temperature -40°C to +105°C
Main Features
• High-speed 1T 8051 CPU
• 16 KB Flash with ISP/IAP support
• 12-bit ADC (up to 800 kSPS)
• Dual UART, SPI, I²C/TWI interfaces
• Up to 8-channel PWM
• DMA controller
• LIN protocol support
• RTC, Watchdog Timer, Brown-Out Detection
• Industrial temperature range
• Low-power operating modes
Typical Applications
• LED Drivers
• Motor Controllers
• Home Appliances
• Industrial Automation
• Smart Sensors
• Automotive Lighting
• Power Supplies
• Consumer Electronics
Package
• Part Number: MG82F6D17AE20
• Package Type: 20-Pin DIP (Through-Hole)
