Megawin MG82F6D16AE28 is a high-performance 8-bit 8051-based microcontroller featuring 16KB Flash Memory, 1KB RAM, dual UART, SPI, I2C, LIN support, DMA, and multiple PWM channels. It operates from 1.8V to 5.5V and is supplied in a 28-pin PDIP package, making it suitable for industrial, consumer, and embedded control applications.
Key Features
• 1-T 8051 CPU Architecture
• 16KB Flash Memory
• 1KB Data RAM
• Operating Voltage: 1.8V to 5.5V
• 28-Pin PDIP Package
• Dual UART Interface
• SPI, I2C (TWI), LIN Communication
• DMA Controller
• Multiple Timers & PWM Outputs
• In-System Programming (ISP) Support
• Industrial Temperature Compatibility
Applications
• Industrial Automation
• Motor Control
• Home Appliances
• Power Supplies
• Consumer Electronics
• LED Lighting Controllers
• Embedded Control Systems
• IoT Devices
• Instrumentation Equipment
Technical Specifications
Parameter Specification
Brand Megawin
Part Number MG82F6D16AE28
MCU Type 8-Bit 8051 MCU
Flash Memory 16KB
RAM 1KB
Package PDIP-28
Operating Voltage 1.8V–5.5V
Communication UART ×2, SPI, I2C, LIN
Mounting Type Through Hole
RoHS Yes
