KBL10-4 Amp Bridge Rectifier
General-purpose use in AC/DC bridge full wave rectification for monitor, TV, printer, SMPS, adapter, audio equipment, and home appliances applications.
Features/Specs:
Part No: KBL10
Make: Good-Ark
Peak Reverse Voltage: 1000V
Forward Voltage: 1.1V
Forward output rectified current: 4A
Max Surge Current: 200A
Reverse Current: 5uA
Reverse Voltage: 700V
Minimum Operating Temperature: – 50°C
Maximum Operating Temperature: + 150°C
Mounting Style: Through Hole
Package/Case: KBL
Length: 19.5mm
Width: 6.5mm
Height: 16.3mm
Weight: 6gm
