Key Specifications
Parameter Specification
Manufacturer Infineon Technologies
Part Number FP35R12W2T4
Module Type Three-Phase PIM (Power Integrated Module)
IGBT Technology TRENCHSTOP™ IGBT4
Voltage Rating (VCES) 1200 V
Collector Current (IC) 35 A
Package EasyPIM™ 2B
VCE(sat) (Typical) 1.85 V
Diode Technology Emitter Controlled 4 Diode
Temperature Sensor Integrated NTC
Mounting Screw Mount
Gate-Emitter Voltage ±20 V
Application Motor Drives, Servo Drives, Industrial Inverters, HVAC, UPS, AC Drives, Power Converters
Features
• 1200V / 35A IGBT Module
• Low conduction losses
• Fast switching performance
• Integrated three-phase rectifier and inverter
• Built-in NTC temperature sensor
• Low stray inductance design
• EasyPIM™ compact package
• High reliability for industrial applications
• RoHS compliant
Typical Applications
• Variable Frequency Drives (VFD)
• AC Motor Drives
• Servo Drives
• Industrial Automation
• Air Conditioner Compressors
• UPS Systems
• Welding Equipment
• Renewable Energy Inverters
