BY255 – 1300V 3A Fast Recovery Diode – DO-27 Package
Fast Recovery Diode is a semiconductor device that possesses a short reverse recovery time for rectification purposes at high frequencies. A quick recovery time is crucial for the rectification of high-frequency AC signals. This product is known as 6A Fast Recovery Diode, Component, Diodes, Fast Recovery Diode, FR607, FR607 Diode, FR607 Diode 6.0A Fast Recovery Diode, Rectifiers, BY251, BY252, BY253, BY254.
Features:
Low-cost construction
Low forward voltage drop
Low reverse leakage
High forward surge current capability
High temperature soldering guaranteed: 260/10 secods/.375”(9.5mm)lead length at 5 lbs(2.3kg) tension
Mechanical Data:
Case: Transfer molded plastic
Epoxy: UL94V-O rate flame retardant
Polarity: Color band denotes cathode end
Lead: Plated axial lead, solderable per MIL-STD-202E method 208C
Mounting position: Any
Weight: 0.042 ounce, 1.19 grams
Features/Specs:
Manufacturer Part No: BY255
Manufacturer: Master Instrument Corporation(MIC)
Repetitive Peak Reverse Voltage: 1300V
Maximum RMS Voltage: 910V
Maximum DC Blocking Voltage: 1300V
Maximum Average Forward Rectified Current: 3A
Peak Forward Surge Current: 125A
Instantaneous Forward Voltage: 1.1V
Typical Junction Capacitance: 40pF
Typical Thermal Resistance: 30°C/W
Operating Junction Temperature Range: -55°C ~ +150°C
Mounting Style: Through Hole
Package/Case: DO-27
Application:
Extreme fast switches
Can be used to prevent reverse polarity problem
Protect Power electronic switches that are operating with high switching frequency.
Used as a protection device
Current flow regulators
