The 7MBR50VP120-50 FUJI IGBT Module is a high-quality, compact power module designed for industrial applications requiring reliable switching and high efficiency. Part of FUJI's EconoPIM™ V series, this IGBT module features a built-in converter and brake circuit, making it ideal for inverter, servo, and UPS systems. It ensures low saturation voltage (VCE(sat)) and smooth operation, optimizing performance and energy efficiency in high-power circuits.
Key Features:
Type: EconoPIM™ V Series IGBT Module
Voltage Rating: 1200 V
Current Rating: 50 A
Built-in Converter & Brake Circuit: PIM with diode bridge and dynamic brake
Low VCE(sat): Reduces conduction losses
Package Type: Compact PCB mounting module
High Reliability: Suitable for industrial-grade applications
Easy Installation: Designed for seamless PCB integration
Applications:
Industrial Inverters
NC Servo Drives
UPS Systems
Motor Drives & Motion Control
Renewable Energy Converters
High-power switching systems
Technical Specifications:
Parameter
Value
Module Type
EconoPIM™ V Series
Collector-Emitter Voltage (VCE)
1200 V
Collector Current (IC)
50 A
Gate-Emitter Voltage (VGE)
±20 V
Power Dissipation
180 W (typical)
Built-in Diode Bridge
Yes
Brake Circuit
Yes (Dynamic brake)
Mounting Type
PCB Mount
Switching Frequency
Up to 10 kHz
Operating Temperature
-20°C to 125°C
Benefits:
High Efficiency: Low conduction and switching losses
Compact Design: Saves PCB space
Versatile Use: Suitable for multiple industrial applications
Reliable Operation: Built-in protection and brake circuitry
Optimized Performance: Stable switching under heavy loads
