0.1uF 630V 5% CBB22 Polyester Film Capacitor 15mm ...
66f937ea690596e0fd624562"
0.1uF 630V 5% CBB22 Polyester Film Capacitor 15mm Pitch
CBB22 0.1uF 630V 5% Polyester Film Capacitor 15mm Pitch (originally known as a condenser) is a passive two-terminal electrical component used to store energy electrostatically in an electric field. The Polyester Capacitor is also known as Polyester Film Capacitors has the dielectric material made of a polymer called polyethylene terephthalate (PET). This is the reason why this capacitor is sometimes referred to as PET Film Capacitor. There are many manufacturers for Polyester Capacitor and out of which Hostaphan is the leading one. Addressing the vendor name, the Polyester Capacitor is also sometimes called a Mylar Capacitor.
Feature/Specs:
Part No: 104J 630V
Make: Vishay / BC Components
Capacitance: 100nf/ 0.1uf
Voltage: 630VAC
Tolerance: ±5%
Dimensions: 16.5×5.5×9 mm
Maximum Operating Temperature: -40°C to +105°C
Terminal Type: Through Hole
Lead Diameter: 0.8mm
Lead Pitch: 15mm
Length: 16.5 mm
width: 5.5 mm
Height: 9 mm
