Vishay SA9.0CA-E3/73 TVS DIODE
Key Specifications
Parameter Value
Part Number SA9.0CA-E3/73
Device Type Bidirectional TVS (Transient Voltage Suppressor) Diode
Peak Pulse Power 500 W
Stand-off Voltage (VRWM) 9.0 V
Breakdown Voltage 10.0 V (typical range around 10–11.1 V)
Clamping Voltage 15.4 V (max)
Peak Pulse Current 32.5 A
Package DO-15 (DO-204AC), Axial Lead
Polarity Bidirectional (CA suffix)
Operating Temperature -55°C to +175°C
Compliance RoHS
Packing Ammo Pack (2000 pcs/box)
Applications
• Power supply protection
• Industrial control equipment
• SMPS
• PLCs
• Telecom equipment
• Automotive electronics
• DC line surge protection
