CD4066 Quad Bilateral Switch IC DIP-14 Package The CD4066 device is a quad bilateral switch intended for the transmission or multiplexing of analog or digital signals. It is pin-for-pin compatible with the CD4016B device but exhibits a much lower on-state resistance. In addition, the on-state resistance is relatively constant over the full signal input range.The CD4066B device consists of four bilateral switches, each with independent controls. Both the p and the n devices in a given switch are biased on or off simultaneously by the control signal. The well of the n-channel device on each switch is tied to either the input (when the switch is on) or to VSS (when the switch is off). This configuration eliminates the variation of the switch transistor threshold voltage with input signal and, thus, keeps the on-state resistance low over the full operating-signal range.Tags, CD4066 Quad Bilateral Switch, 595-CD4066BE, CD4066 Bilateral Switch, CD4066BM Quad Bilateral Switch, CD4066BM Bilateral Switch, CD4066BM, CD4066BM96, CD4066BQDRQ1, CD4066BM96E4, CD4066BM96G4, CD4066BPWR, CD4066BPW, CD4066BE, CD4066BNS, CD4066BMT, CD4066BEE4, CD4066BNSR, CD4066BPWG4, CD4066BPWRG4 Features: 15-V Digital or ±7.5-V Peak-to-Peak Switching 125-Ω Typical On-State Resistance for 15-V Operation Switch On-State Resistance Matched to Within 5 Ω Over 15-V Signal-Input Range On-State Resistance Flat Over Full Peak-to-Peak Signal Range High On or Off Output-Voltage Ratio: 80 dB Typical at fis = 10 kHz, RL = 1 kΩ High Degree of Linearity: <0.5% Distortion Typical at fis = 1 kHz, Vis = 5-Vp-p VDD – VSS ≥ 10-V, RL = 10 kΩ Extremely Low Off-State Switch Leakage, Resulting in Very Low Offset Current and High Effective Off-State Resistance: 10 pA Typical at VDD – VSS = 10-V, TA = 25°C Extremely High Control Input Impedance (Control Circuit Isolated From Signal Circuit): 1012 Ω Typical Low Crosstalk Between Switches: –50 dB Typical at fis = 8 MHz, RL = 1 kΩ Matched Control-Input to Signal-Output Capacitance: Reduces Output Signal Transients Frequency Response, Switch On = 40 MHz Typical 100% Tested for Quiescent Current at 20-V 5-V, 10-V, and 15-V Parametric Ratings Features/Specs: Manufacturer Part No: CD4066BE Manufacturer: Texas Instruments Series: CD4066B Product Category: Analogue Switch IC Product Type: Analog Switch IC Number of Channels: 4 Channel Configuration: 4 x SPST On Resistance: 240 Ohms On-Time: 30 ns Off Time: 30 ns Supply Type: Single Supply, Dual Supply Operating Supply Voltage: 3 ~ 18V Supply Current: 5 uA Minimum Dual Supply Voltage: +/- 7.5 V Maximum Dual Supply Voltage: +/- 7.5 V Operating Temperature: -55 ~ +125°C Mounting Style: Through Hole Package/Case: PDIP-14 Weight: 1 gm Applications: Analog Signal Switching and Multiplexing: Signal Gating, Modulators, Squelch Controls, Demodulators, Choppers, Commutating Switches Digital Signal Switching and Multiplexing Transmission-Gate Logic Implementation Analog-to-Digital and Digital-to-Analog Conversions Digital Control of Frequency, Impedance, Phase, and Analog-Signal Gain Building Automation
