L7809CV 9V Positive Voltage Regulator IC TO220 is a highly reliable fixed output linear voltage regulator designed to provide a stable and regulated 9V DC output voltage for a wide range of industrial, commercial and consumer electronic applications. Manufactured by STMicroelectronics, the L7809CV belongs to the popular 78XX voltage regulator series and is widely used in power supplies, automation systems, instrumentation equipment, battery chargers, telecom devices, embedded systems and electronic control circuits.
The device delivers excellent line regulation, load regulation, thermal protection and short circuit protection, ensuring safe and stable operation under varying load conditions. Its robust TO220 package enables easy mounting and efficient heat dissipation for long-term reliability.
Diode House is one of India's leading stockists and distributors of genuine industrial electronic components, supplying original voltage regulators, ICs, MOSFETs, IGBTs, Optocouplers, Diodes, Bridge Rectifiers, Capacitors and Semiconductors to OEMs, EMS companies and industrial manufacturers across India.
________________________________________
Technical Specifications
Parameter Specification
Part Number L7809CV
Manufacturer STMicroelectronics
Product Type Positive Voltage Regulator IC
Output Voltage 9V Fixed
Package TO220
Output Current Up to 1.5A
Input Voltage Up to 35V
Dropout Voltage Standard Linear Regulator
Line Regulation Excellent
Load Regulation Excellent
Output Type Fixed Output
Mounting Type Through Hole
Operating Temperature 0°C to +125°C
Thermal Shutdown Yes
Current Limiting Yes
Short Circuit Protection Yes
RoHS Compliant Yes
