The AD826AN from Analog Devices is a high-speed, low-power dual operational amplifier designed for high-bandwidth analog signal processing. It offers 50 MHz bandwidth, 350 V/µs slew rate, excellent DC accuracy, and high output current capability, making it suitable for instrumentation, video, active filters, ADC/DAC buffering, and industrial electronic applications.
Product Details
Part Number: AD826AN
Manufacturer: Analog Devices (ADI)
Device Type: Dual High-Speed Operational Amplifier
Package: DIP-8 (Through-Hole)
Mounting Type: Through-Hole
Channels: 2 (Dual Op-Amp)
Key Features
Unity Gain Bandwidth: 50 MHz
Slew Rate: 350 V/µs
Supply Voltage: ±5 V to ±15 V or Single +5 V
Low Input Offset Voltage: 2 mV (Max)
High Output Drive: 50 mA (Min) per amplifier
Low Power Consumption
Unity-Gain Stable
Applications
High-speed signal amplification
Video amplifiers
ADC/DAC buffer circuits
Active filters
Instrumentation
Data acquisition systems
Medical and industrial electronics
Communication equipment
